Data Sheet

* 23AWG bare copper wire * 4 pair FTP shielding * CMR rated * ETL (US and Canada) listed * RoHS compliant Solid Wire : also called solid-core or single-strand wire, consists of one piece of metal wire. Stranded wire is composed of a bundle of small-gauge wires to make a larger conductor and more flexible than solid wire. Solid wire is generally used for in-wall wiring where there is little need for flexibility in the wire. CMR : The 'R' in CRM is for 'Riser'. Riser type cables are engineered to prevent the spread of fire from floor to floor and are suitable for vertical shaft applications. CMP : The 'P' in CMP is for Plenum. Cables meeting type CMP requirements are suitable for installation in ducts and plenums without the use of conduit. These cables are designed for fire resistance and low-smoke and toxin producing characteristics. CM/CMH/CMG : CM is used for general building wiring such as residential house. CM cables are used in areas other than plenums and risers. FTP shield : FTP (foil screened twisted pair) cable is a cable containing multiple pairs of copper wire enclosed in a sheath of aluminum foil. It's used in wiring systems in buildings or other environments where heavy noise adjacent to the wire might cause interference. The foil provides insulation not afforded by UTP (unshielded twisted pair), the most common kind of structural wiring.
