Spec Sheet
PF series server enclosures are versatile and feature-rich enclosures engineered for demanding IT environments, including high density and remote edge environments. These enclosures features enhanced frame design, easier equipment rail adjustment,
efficient accessory and cable organization, smarter air flow management to facilitate a faster installation, greater flexibility and
reduced operating costs. .
Features:
Best-in-class energy efficiency, Air-Seal airflow optimization
4,400Lb stationary and 2,700Lb rolling load rating.
Heavy gauge rails, galvanized with automatic potential equalization built in.
Reinforced lockable door and main chassis for increased security.
Integrated cable managers and grommet for streamlined cabling.
Locking, removable and reversible front and split rear doors.
Pre-installed casters and internal access leveling feet.
Specs:
| Type: |
Enclosure |
| Style: |
Floor-Standing |
| Rack Height: |
42U |
| Rack Depth (in. / mm): |
47.2 / 1200 |
| Maximum Rail Depth (in. / mm: |
43.3 / 1100 |
| Front Door Type: |
Perforated |
| Load capacity - Statiionary (lbs / kg) |
4,400 / 2,000 |
| Number of vertical mounting rails: |
4 |
| Number of L brackets: |
N/A |
| Shelves: |
N/A |
| Cable access: |
Top, Bottom |
| Unit Dimensions (H x W x D / in.): |
81 x 23.6 x 47.5 |
Due to the dimensions of the box, Dimensional Weight Rates will apply for this item. What is Dimensional Weight?
** Free freight does NOT apply to this item. **
