Data Sheet
SQ Series Wall Mount Cabinets organize and secure EIA-standard 19-inch rackmount equipment in network closets, offices,
classrooms, and other locations with limited floor space. Welded structure delivers exceptional strength and rigidity supporting
heavier equipment. Removable side panels for installation of accessories and monitoring equipment. Frameless front door with
tempered glass and turning angle over 180 degrees
Features:
Fits rack equipment up to 20 in deep.
Maximum load capacity of 100 lbs.
Removable door, and side panel.
Reinforced lockable door.
Cable pass-through on top and bottom.
Rugged welding frame structure with ventilation on at front, sides, top and bottom.
Ships fully assembled.
Specs:
| Type: |
Enclosure |
| Style: |
Wall-Mount |
| Rack Height: |
6U |
| Rack Depth (in. / mm): |
23.6 / 600 |
| Maximum Device Depth (in. / mm): |
20.7 / 527 |
| Front Door Type: |
Tempered Glass |
| Load capacity (lbs / kg): |
100 / 45 |
| Number of vertical mounting rails: |
4 |
| Number of L brackets: |
2 |
| Shelves: |
No |
| Cable access: |
Top, Bottom |
| Unit Dimensions (H x W x D / in.): |
14.5 x 21.25 x 23.6 |
Due to the dimensions of the box, Dimensional Weight Rates will apply for this item. What is Dimensional Weight?
** Free freight does NOT apply to this item. **
